BandSaw

The Preferred Solution for High-Precision Sawing

We have focused on the R&D and production of band saw machines for many years, and manufacture efficient, stable and precise sawing equipment in accordance with German process standards, providing one-stop sawing solutions for the metal processing industry.

Browse Products Customized Solutions

For over 25 years, SMS Machinery has been at the forefront of sheet metal machinery, combining innovation with engineering excellence to deliver industry-leading solutions.

Advanced Technology:Our sheet metal machinery incorporate the latest CNC technology and hydraulic systems for unmatched precision
Global Presence:With distribution networks across 20+ countries, we provide localized support and service to clients worldwide.
Quality assurance:All our machines undergo rigorous testing and meet international standards and 48 hours testi

Core Product Features

SMS Band Saw Machines implement full-process quality control, with core components adopting imported configurations, creating industry-leading sawing equipment.

Request A quote

The sawing transmission structure is optimized, increasing sawing efficiency by 30% and significantly shortening the processing cycle.

High-precision guide rails and servo control systems are adopted, with a sawing accuracy of up to ±0.1mm.

The machine body is welded with thickened steel plates and undergoes aging treatment, ensuring no vibration during operation and a long service life.

It features a user-friendly touch interface and one-click operation, supporting automatic feeding and fixed-length sawing.

It is driven by a variable-frequency motor. Compared with traditional equipment, its energy consumption is reduced by 25% and saw blade wear is decreased by 15%, significantly lowering production costs.

It is equipped with multiple safety devices such as overload protection, emergency braking, and splash-proof shields, complying with safety standards and ensuring the safety of operators.

Product Browsing

The structure of a band saw machine mainly includes: saw frame part, guide part, transmission part, tensioning part, base part, saw frame feeding system, material feeding and length-setting part, electrical system, hydraulic system, lubrication system, and cooling & chip removal device.

Sawing Capacity (mm): 850*850H*850
Band Saw Blade Linear Speed (m/min): 20-100
Band Saw Blade Specification (mm): 54×1.6×9577
Main Motor Power (KW): 11
Hydraulic Motor (KW): 3.75
Cooling Pump (KW): 0.25
Workbench Height (mm): 830
Workpiece Clamping Method: Hydraulic Clamping
Saw Blade Tensioning Method: Hydraulic Tensioning
Overall Dimension (mm): 4320×2130×3560
Main Transmission Structure: Worm Gear Reducer
Band Saw Blade Cleaning: Circular Steel Wire Brush

The Double-Column Horizontal Band Saw Machine Series features a scientific and reasonable structure, a neat and elegant appearance, high cutting efficiency, and a long service life. It is an ideal blanking equipment for medium-sized materials.

The cutting speed is hydraulically controlled and adopts stepless speed regulation.
The guide block structure is scientific and reasonable, which extends the service life of the saw blade.
The double-column structure ensures stable sawing and high precision.
Workpiece clamping combines hydraulic and manual operation, enabling convenient operation.
The saw blade cuts down in the middle of the jaw, facilitating the sawing of short workpieces.
Sawing Capacity (mm): 400*400H*700
Band Saw Blade Linear Speed (m/min): 20, 33, 48, 75
Band Saw Blade Specification (mm): 41×1.3×5040
Main Motor Power (KW): 4
Hydraulic Motor (KW): 0.75
Cooling Pump (KW): 0.09
Workbench Height (mm): 610
Workpiece Clamping Method: Hydraulic Clamping
Saw Blade Tensioning Method: Manual
Overall Dimension (mm): 2350×1350×1400
Main Transmission Structure: Worm Gear
Band Saw Blade Cleaning: Circular Steel Wire Brush

The Tackle Vertical Band Saw Machine Series is a new product independently developed by our company through optimized design. It is customized to meet the needs of the iron and steel mold industry and integrates the essence of similar products in the domestic and international band saw machine industry. It serves as a blanking equipment for plates.

An infrared tool-setting system is used to calibrate the sawing position of the workpiece, making the operation simple and convenient.
A hydraulic material-ejecting device is equipped to coordinate with material feeding.
An automatic shutdown sensor for band saw breakage is installed to ensure operational safety.
The hydraulic system adopts a split-type design with two hydraulic stations, enabling the equipment to operate at low temperatures.
Stepless Speed Regulation Knob and LCD Band Saw Speed Meter
Sawing Speed Adjustment Knob and LCD Sawing Speed Meter
Sawing Capacity (mm): 1000H×1500W
Band Saw Blade Linear Speed (m/min): 20-70
Band Saw Blade Specification (mm): 67×1.6×8888
Main Motor Power (KW): 7.5
Hydraulic Motor (KW): 1.5/2.2
Cooling Pump (KW): 0.12
Workbench Height (mm): 1490
Workpiece Clamping Method: Hydraulic Clamping
Saw Blade Tensioning Method: Hydraulic
Overall Dimension (mm): 4300*400*2600
Main Transmission Structure: Gear Reducer
Band Saw Blade Cleaning: Steel Wire Brush
